首页产品室内DIAMOND 125 - 嵌入式无边直射筒灯

DIAMOND 125

嵌入式无边直射筒灯

DIAMOND 125

光效图

产品规格:
灯具类型:嵌入式无边直射筒灯
开孔尺寸:ø 125 mm
功率:20W 25W 30W 35W 40W 45W
光束角:12D 15D 27D 36D 50D
色温:2700K 3000K 3500K 4000K
净重:0.95KG
散热器材质:铝
表面工艺:喷粉
线条图:
产品特征:


可选配件:
反射器颜色:
外框颜色:

型号选择:

功率
  • 功率
  • 20W
  • 25W
  • 30W
  • 35W
  • 40W
  • 45W
光束角
  • 光束角
  • 12°
  • 15°
  • 27°
  • 36°
  • 50°
显示指数
  • 显示指数
  • Ra>90
色温
  • 色温
  • 2700K
  • 3000K
  • 3500K
  • 4000K
调光方式
  • 调光方式
  • 1-Non Dim
  • 2-可控硅调光
  • 3-0-10V调光
  • 4-DALI调光
边框颜色
  • 边框颜色
  • 白色
反射器颜色
  • 反射器颜色
  • 镜面
防护等级
  • 防护等级
  • 20-IP20
配件
  • 配件
  • 蜂窝网

  • 型号

  • 整灯光通量

  • 功率

  • 光束角

  • 显示指数

  • 色温

  • 规格书

  • DWG

  • IES

  • 安装手册

  • 收藏

型号
DR02319-20129027
DR02319-20129030
DR02319-20129035
DR02319-20129040
DR02319-20159027
DR02319-20159030
DR02319-20159035
DR02319-20159040
DR02319-20279027
DR02319-20279030
DR02319-20279035
DR02319-20279040
DR02319-20369027
DR02319-20369030
DR02319-20369035
DR02319-20369040
DR02319-20509027
DR02319-20509030
DR02319-20509035
DR02319-20509040
DR02319-25129027
DR02319-25129030
DR02319-25129035
DR02319-25129040
DR02319-25159027
DR02319-25159030
DR02319-25159035
DR02319-25159040
DR02319-25279027
DR02319-25279030
DR02319-25279035
DR02319-25279040
DR02319-25369027
DR02319-25369030
DR02319-25369035
DR02319-25369040
DR02319-25509027
DR02319-25509030
DR02319-25509035
DR02319-25509040
DR02319-30129027
DR02319-30129030
DR02319-30129035
DR02319-30129040
DR02319-30159027
DR02319-30159030
DR02319-30159035
DR02319-30159040
DR02319-30279027
DR02319-30279030
DR02319-30279035
DR02319-30279040
DR02319-30369027
DR02319-30369030
DR02319-30369035
DR02319-30369040
DR02319-30509027
DR02319-30509030
DR02319-30509035
DR02319-30509040
DR02319-35159027
DR02319-35159030
DR02319-35159035
DR02319-35159040
DR02319-35279027
DR02319-35279030
DR02319-35279035
DR02319-35279040
DR02319-35369027
DR02319-35369030
DR02319-35369035
DR02319-35369040
DR02319-35509027
DR02319-35509030
DR02319-35509035
DR02319-35509040
DR02319-40159027
DR02319-40159030
DR02319-40159035
DR02319-40159040
DR02319-40279027
DR02319-40279030
DR02319-40279035
DR02319-40279040
DR02319-40369027
DR02319-40369030
DR02319-40369035
DR02319-40369040
DR02319-40509027
DR02319-40509030
DR02319-40509035
DR02319-40509040
DR02319-45279027
DR02319-45279030
DR02319-45279035
DR02319-45279040
DR02319-45369027
DR02319-45369030
DR02319-45369035
DR02319-45369040
DR02319-45509027
DR02319-45509030
DR02319-45509035
DR02319-45509040
整灯光通量
910LM
958LM
987LM
1006LM
1068LM
1124LM
1158LM
1180LM
1638LM
1724LM
1776LM
1810LM
1690LM
1779LM
1832LM
1868LM
1438LM
1514LM
1559LM
1590LM
1008LM
1061LM
1093LM
1114LM
1272LM
1339LM
1379LM
1405LM
1935LM
2037LM
2098LM
2139LM
2006LM
2112LM
2175LM
2218LM
1719LM
1810LM
1864LM
1901LM
1089LM
1146LM
1180LM
1203LM
1438LM
1514LM
1559LM
1590LM
2256LM
2375LM
2446LM
2494LM
2333LM
2456LM
2530LM
2579LM
2011LM
2117LM
2180LM
2223LM
1639LM
1725LM
1777LM
1812LM
2704LM
2846LM
2932LM
2989LM
2788LM
2935LM
3023LM
3081LM
2406LM
2532LM
2608LM
2659LM
1760LM
1853LM
1908LM
1945LM
2889LM
3042LM
3133LM
3194LM
2977LM
3133LM
3227LM
3290LM
2574LM
2710LM
2791LM
2845LM
3139LM
3304LM
3403LM
3469LM
3240LM
3411LM
3513LM
3581LM
2815LM
2963LM
3052LM
3111LM
功率
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
20W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
25W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
30W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
35W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
40W
45W
45W
45W
45W
45W
45W
45W
45W
45W
45W
45W
45W
光束角
12°
12°
12°
12°
15°
15°
15°
15°
27°
27°
27°
27°
36°
36°
36°
36°
50°
50°
50°
50°
12°
12°
12°
12°
15°
15°
15°
15°
27°
27°
27°
27°
36°
36°
36°
36°
50°
50°
50°
50°
12°
12°
12°
12°
15°
15°
15°
15°
27°
27°
27°
27°
36°
36°
36°
36°
50°
50°
50°
50°
15°
15°
15°
15°
27°
27°
27°
27°
36°
36°
36°
36°
50°
50°
50°
50°
15°
15°
15°
15°
27°
27°
27°
27°
36°
36°
36°
36°
50°
50°
50°
50°
27°
27°
27°
27°
36°
36°
36°
36°
50°
50°
50°
50°
显示指数
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
色温
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
2700K
3000K
3500K
4000K
规格书
DWG
IES
安装手册
收藏
